CONTEG SOHO On-Wall

ACP-OW Series 19" Soho Racks




PDF_014_36x36.jpgDownload the datasheet

Jellemzők

Height: 550 mm
Width: 530 mm
Depth: 140 mm
Color:RAL 7035 (other colour designs available upon request)

Alkalmazás

The SOHO On-Wall 19" distribution enclosure is an aesthetically pleasing and cost-effective solution for the developer/homeowner. It also offers a lot of flexibility during the installation process. The On-Wall solution's low profile makes it ideally suited for residential spaces where space may be limited. The SOHO On-Wall solution offers 6Us of mounting space ad gives you flexibility when mounting standard 19" equipment, such as patch panels, wire managers and Integrated Access Devices. Equipment is secured within a very small footprint that remains hidden until access is required. Wire management is built in to the SOHO On-Wall to ensure that copper and/or fiber cables can be managed properly.

Standard configuration

  • 1 pair of fixed 19" vertical extrusions (4U)
  • 1 pair of fixed 19" horizontal extrusions (2U)
  • 1 perforated metal sheet door with lock
Code Box dimensions in mm Vertical extrusions Horizontal extrusions External dimensions including packing in mm Gross weight in kg
H W D U* UD** U* UD** H W D
ACP-OW-55/53/14 550 530 155 4 90 2 300 630 595 170 12

* length of extrusions in units
** max. depth of installed equipment in mm
