4U support frame

Features

  • Can be mounted in a 19 "or 21" standard filing cabinet or director frame.
  • The mounting plane of the support frame can be mounted in three depths.
  • Height (H): 4U - 178 mm.
  • Width (W): 19 "or 21".
  • Depth (D): 200 mm.
  • RAL7035 powder coated box and components.
  • Structure: 3U high module holder frame and 1U high strand spare box.
  • The front panel of the box is fitted with 5 plastic cable ties. The front panel can be removed and transported without baffles if required.
  • A maximum of 12 3U high and 35 mm front panel width or 10 3U high and 40 mm front panel width card-type modules can be installed in the rack. Unused card positions can be covered with blanking plates.
  • Plastic rails guide the card-type modules in the frame.
  • Double-sided rear cable entry. The incoming cable compartment can be placed in the 1U high compartment box.
  • Accessories: 4 basket nuts and mounting screws.

Applications

  • Telecommunications networks
  • CATV networks
  • Data networks
  • LAN, MAN, WAN
  • FTTx, PON
